Item Specifics:
* Is_customized : Yes
* Brand Name : Noyafa
* Model Number : NF-816
* Place of Origin : Shenzhen.China
* Tracing type: Underground, Buried wires and Other Hidden wires
* Length range:up to 1000 feet
* Depth range: up to 3 feet
* Power : 9V Alkaline battery
* Certificates: CE
* Warranty : 1 Year
Main functions:
1. Trace and locate underground or in-wall wires;
2. Enables cables to be located before drilling ;
3. The detection range is 3 feet and cable length 3000 feet.
4. Widely applied in Pet fence
5. White LED Flash Light.
Technical indexes:
| NF-816 Transmitter specifications |
|
| Tone frequency |
200kHz |
| The Max length distance |
1000 feet |
| The Max depth distance |
3 feet |
| The Max. working current |
Less than 70mA |
| Tone mode |
1 Tone |
| Max. signal voltage |
15Vp-p |
| Signal display |
Signal tone, Antenna |
| Voltage protection |
AC 60V/DC 42V |
| Battery type |
DC9.0V（NEDA 1604/6F22) x 1pc |
| Dimensions (LxWxD) |
49 x 135 x 33mm |
| NF-816 Receiver specifications |
|
| Frequency |
200kHz |
| The Max. working current |
Less than 70mA |
| Earphone jack |
1 |
| Battery type |
DC9.0V（NEDA 1604/6F22) x 1pc |
| Dimensions (LxWxD) |
43 x 168 x 27mm
|
